Resin

Usage

XY Resolution

Color(s)

HTUHR

 Engineering 5 to 25um Yellowish clear

UHR

 General Purpose 5 to 25 um Yellowish clear or Black

PDMS

 PDMS Molding 5 to 25 um Yellowish clear

BIO

 Biomedical research  15 to 37 um Orange clear

FLEX

 Flexible device 15 to 37 um Yellowish clear

CLEAR

 Microfluidics 25 to 37 um Transparent

High Temperature UHR Resin

Usage:  Ultra High Resolution Resin for High Temperature Applications
XY Resolution: 5 – 25 Microns
Wavelengths: 385 or 365nm
Colors: Yellowish clear
Downloads: Material Safety Data Sheet, Technical Data Sheet

This resin is the strongest among all our resins.   It also has a heat deflection temperature of 235 degree Celsius.

UHR Resin

Usage:  Ultra High Resolution General Purpose
XY Resolution: 5 – 25 Microns
Wavelengths: 385 or 365nm
Colors: Yellowish Clear
Downloads: Material Safety Data Sheet, Technical Data Sheet

For those who need prints that require the extra details and high resolution, UHR resin is the perfect resin for you. Specifically, formulated for general purpose research and engineering.  UHR resin has been widely used in printing microchannel, microneedle and microlattice.

PDMS Molding UHR Resin

Usage: Ultra High Resolution Resin for PDMS Molding
XY Resolution: 5 – 25 Microns
Wavelengths: 385 or 365nm
Colors: Yellowish clear
Downloads: Material Safety Data Sheet, Technical Data Sheet

This version of UHR resin is used for PDMS molding at a maximum temperature of 120 Celsius degree for 20 minutes.

BioHR Resin

Usage: High Resolution Resin for Biocompatible Research
Resolution: 5 – 25 Microns
Wavelengths: 385 or 365nm
Colors: Yellowish Clear
Downloads: Material Safety Data Sheet, Technical Data Sheet

BioHR Resin is a biocompatible high resolution resin for biomedical research.

FLEX Resin

Usage: High Resolution Flexible Applications
Resolutions: 15 – 25 Microns
Wavelengths: 385 or 365nm
Colors: Yellowish clear
Downloads: Material Safety Data Sheet, Technical Data Sheet

FLEX resin is a high resolution flexible resin for engineering

Clear Resin

Usage: High resolution general purpose 3D printing
XY Resolution: 25 Microns
Wavelengths: 385 or 365nm
Colors: Clear
Downloads: Material Safety Data Sheet, Technical Data Sheet

This is a high resolution clear resin for general purpose.
